Europull Universal Beam Clamp (Super Clamp)
Heavy-duty universal super clamp designed for lifting, pulling, and rigging from overhead steel beams. Can accommodate side loading and angle pulls with an integrated lower shackle point.
- Capacity2t - 10t
- TypeSuper Clamp
Need sizing help? Email info@europull.com
- Certified to EN 13155
- 4 models available
Technical Specifications
Model-by-model data for the Europull Universal Beam Clamp (Super Clamp) range.
| Model | Capacity (Tons) | Flange Range (mm) | Test Load (kN) | Net Weight (kg) |
|---|---|---|---|---|
| EP-UBC02 | 2.0 Ton | 75 - 200 mm | 30.0 kN | 7.0 kg |
| EP-UBC03 | 3.0 Ton | 75 - 250 mm | 45.0 kN | 12.0 kg |
| EP-UBC05 | 5.0 Ton | 100 - 305 mm | 75.0 kN | 18.5 kg |
| EP-UBC10 | 10.0 Ton | 150 - 305 mm | 150.0 kN | 32.0 kg |
Need a model or configuration not listed? Email our engineering team or download the full catalog (PDF).
Key Parameters
| Parameter | Specification | Highlight |
|---|---|---|
| Standard / Compliance | EN 13155 / ASME B30.20 | Certified |
| Rated Capacity | 2 Ton to 10 Ton | 2t - 10t |
| Side Loading | Approved for Angle & Side Loading Pulls | Universal |
| Flange Adjustment | 75 mm to 305 mm Adjustability | Secure Screw |
| Suspension Point | Integrated Swiveling Shackle Eye | Direct Rigging |
| Safety Factor | 5:1 Safety Margin | Proof Tested |
Key Features & Advantages
Multi-Directional Loading
Approved for in-line and angled pulling without structural slippage.
Integrated Shackle Eye
Allows direct shackle or hook connection without intermediate adapters.
Standards & Compliance
EN 13155 Compliance
Lifting attachments standard.
CE Certified
Factory load proof tested.
Product Overview
The Europull Universal Super Clamp is the contractor's choice for pipe-hanging, hoist rigging, and winching where loads may be pulled at off-vertical angles.
Frequently Asked Questions
The Europull Universal Beam Clamp (Super Clamp) is available in 4 models: EP-UBC02, EP-UBC03, EP-UBC05, EP-UBC10. Capacity (Tons) ranges from 2.0 Ton to 10.0 Ton. Full figures for every model are in the technical specifications table on this page.
The Europull Universal Beam Clamp (Super Clamp) covers 2t - 10t.
The Europull Universal Beam Clamp (Super Clamp) is manufactured to EN 13155.
The Europull Universal Beam Clamp (Super Clamp)'s side Loading: Approved for Angle & Side Loading Pulls.
The Europull Universal Beam Clamp (Super Clamp)'s flange Adjustment: 75 mm to 305 mm Adjustability.
The Europull Universal Beam Clamp (Super Clamp)'s suspension Point: Integrated Swiveling Shackle Eye.
Click "Request a Quote" on this page to add the Universal Beam Clamp (Super Clamp) to your quote cart, or email info@europull.com with the model code and quantity you need.
